IMX317 USB Camera Module 8MP 4K 30FPS Fixed Focus
Detalhes do produto:
| Place of Origin: | Shenzhen,China |
| Marca: | Sinoseen |
| Certificação: | RoHS |
| Model Number: | SNS-DZ1009-V1.0 |
Condições de Pagamento e Envio:
| Minimum Order Quantity: | 3 |
|---|---|
| Preço: | negociável |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Informação detalhada |
|||
| Type: | USB Camera Module | Sensor: | IMX317 1/2.5 inch |
|---|---|---|---|
| Resolution: | 8MP 3840*2160 | Dimensions: | Customizable |
| Frame Rate: | 30FPS | Lens FOV: | 82°(optional) |
| Interface: | USB | ||
Descrição de produto
| Type | USB Camera Module |
| Sensor | IMX317 1/2.5 inch |
| Resolution | 8MP 3840*2160 |
| Dimensions | Customizable |
| Frame Rate | 30FPS |
| Lens FOV | 82° (optional) |
| Interface | USB |
Still searching for a camera that offers both 4K clarity and high flexibility across various application scenarios? The Sinoseen SNS-DZ1009-V1.0 Camera Module provides ultimate 4K clarity, making it your ideal versatile solution for multiple scenarios.
It features an IMX317 CMOS sensor, supporting 3840 x 2160 4K Ultra HD video with a smooth output of 30 frames per second. This completely addresses the shortcomings of traditional modules in detail capture and motion fluidity. Its fixed-focus design further simplifies integration, enabling reliably clear imaging without complex focusing, effectively reducing design and maintenance costs.
This module's USB interface offers unparalleled plug-and-play convenience, allowing seamless integration into digital cameras, dash cams, sports cameras, security surveillance systems, and even industrial equipment. Whether you need to record high-quality videos for outdoor activities, provide detailed security footage for vehicles, or deliver precise visual feedback for production lines, the SNS-DZ1009-V1.0 can meet your needs.
| Module | SNS-DZ1009-V1.0 |
| Sensor | IMX317 CMOS |
| Image sensor size | 1/2.5 inch |
| Pixel | 8MP |
| Most effective pixels | 3840*2160 |
| Pixel Size | 1.62um*1.62um |
| Frame rate | 30fps |
| Focus type | Fixed focus |
| Output interface | USB2.0 |
| Video output | MJPG/YUV |
| Output formats | RAW Bayer 10bits |
| Max S/N ratio | TBD |
| Dynamic | TBD |
| Storage temperature | -20°C to 70°C |
| Operating temperature | 0°C to 60°C |
| Support OS | WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC |
